Phoenix Contact 3044115 UT series continuity 6.2mm Screws blue 1pc

Phoenix Contact manufactures the 3044115 screw terminal, designed with dimensions of 47.7 x 6.2 x 55 mm and features a blue colour for easy identification. This terminal block is ideal for creating secure electrical connections in switchboards and control panels, ensuring reliable continuity. It is typically used in industrial settings to facilitate organised and efficient wiring.

Type	Continuity
Pitch	6.2mm
No. of Ways	2
Termination	Screw
Width	6.2mm
Wire Gauge (mm²)	6mm²
AWG (min.)	26
Clamp width	6.2mm
Closing plate required	true
Colour	Blue
Connectable conductor cross section fine-strand with cable end sleeve	0.25 - 0.25mm²
Connectable conductor cross section fine-strand without cable end sleeve	0.14 - 6mm²
Connectable conductor cross section multi-wired	0.14 - 1.5mm²
Connectable conductor cross section solid-core	0.14 - 6mm²
Connection	Screws
Cross section (flexible) (min.)	0.14mm²
Cross section (inflexible) (min.)	0.14mm²
Current Rating	41A
Depth	46.9mm
Dim	(L x W x H) 47.7 x 6.2 x 46.9 mm
Explosion-tested version Ex e	true
Flammability Rating	V0
Height	46.9mm
Industrial packaging	No
Inflammability class of insulation material according to UL94	V0
Insulation	PA
Internally connected stages	true
Length	47.7mm
Material insulation body	Other
Misc Attribute	UT 4 BU
Mounting method	DIN rail (top hat rail) 35 mm
Nominal Voltage	1000V
Number of clamp positions per level	2
Number of levels	1.0
Number of Pins	2
Number of Rows	1
Operating Temperature	-60 - 110°C
Rated current In	32A
Rated voltage	1000V
Stripping length (max.)	9mm
Suitable for conductor material	Aluminium/copper
Type of electrical connection 1	Screw connection
Type of electrical connection 2	Screw connection
Wire Gauge (AWG)	10
