Phoenix Contact 2961118 REL-MR-60DC/21 PCB Relay 60V DC 6A 1 Change-over

Phoenix Contact's REL-MR-60DC/21 is a PCB relay capable of handling 60 V DC and 6 A with a single change-over contact. This miniature relay is ideal for use in printed circuit board assemblies where space is limited. It is commonly used in industrial automation and control systems.

Coil Voltage	60V DC
Contact Configuration	1CO (SPDT)
Switching Current	6A
Coil Resistance	20500O
Complete with socket	false
Connection	Solder pins
Contact Material	AgSnO
Control Mode	monostable, 1 coil
Degree of protection (IP)	Other
Depth	15mm
Dimensions	(W x H x D) 5 x 28 x 15 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	28mm
Material contact	N/A
Material of contact insert	Other
Material of contact surface	Untreated
Max. starting current	N/AA
Max. switching capacity	1500VA
Misc Attribute	REL-MR- 60DC/21
Mounting Type	PCB
Nominal Current	0.003A
Number of contacts as change-over contact	1
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Operating voltage AC 50 Hz	- - -V
Operating voltage AC 60 Hz	- - -V
Operating voltage DC	- - -V
Rated control supply voltage AC 50 Hz	- - -V
Rated control supply voltage AC 60 Hz	- - -V
Rated control supply voltage DC	36 - 165V
Relay technology category according to IEC 61810-7	N/A
Type	PCB relay
Type of electric connection	Other
Type of switch contact	Single contact
Voltage type (operating voltage)	N/A
Voltage type for actuating	DC
Width	5.0mm
With detachable clamps	false
With forced-guided contacts	false
With LED indication	false
