The phoenix contact UNO-PS/1AC/5DC/25W rail mounted PSU is a versatile industrial power supply unit delivering 5 V DC at 5 A with a total power of 25 W. It is designed for easy installation on DIN rails, making it ideal for use in various industrial and automation applications. This reliable power supply supports critical operations by ensuring stable voltage output in demanding environments.
| Type |
Rail mounted PSU (DIN) |
| Output Voltage |
5V DC |
| Output Current |
5A |
| Number of Outputs |
1 |
| Power Rating |
25W |
| 1st secondary output voltage |
5 - 5V |
| 2nd secondary output voltage |
- - -V |
| 3rd secondary output voltage |
- - -V |
| Built-in height |
90mm |
| Built-in width |
N/Amm |
| Connection |
Screw terminal |
| Connections |
Screw connector |
| Degree of protection (IP) |
IP20 |
| Degree of protection (NEMA) |
Other |
| Depth |
84mm |
| Dim |
(W x H x D) 22.5 x 90 x 84 mm |
| Direct mounting possible |
false |
| Height |
90mm |
| Input Voltage |
85 V AC 264 V AC |
| Max. output current |
5A |
| Max. output current 1 |
5A |
| Max. output current 2 |
N/AA |
| Max. output current 3 |
N/AA |
| Maximum Input Volage |
264V AC |
| Maximum Temperature |
70°C |
| Min. temperature |
-25°C |
| Minimum Input Volage |
85V AC |
| Misc Attribute |
UNO-PS/1AC/ 5DC/ 25W |
| MTBF |
500000h |
| Nominal value output current 1 |
5A |
| Nominal value output current 2 |
N/AA |
| Nominal value output current 3 |
N/AA |
| Nominal value output voltage 1 |
5V |
| Nominal value output voltage 2 |
N/AV |
| Nominal value output voltage 3 |
N/AV |
| Output voltage stabilized |
true |
| Performance level according to EN ISO 13849-1 |
None |
| Phases |
1 |
| Power Consumption |
61.7VA |
| Power Output |
25W |
| Rated supply voltage AC 50 Hz |
85 - 240V |
| Rated supply voltage AC 60 Hz |
100 - 264V |
| Rated supply voltage DC |
- - -V |
| Secondary voltage adjustable |
false |
| Short-circuit-proof |
true |
| SIL according to IEC 61508 |
None |
| Stabilized |
true |
| Suitable for distribution board |
false |
| Suitable for rail mounting |
true |
| Suitable for safety functions |
true |
| Type of electric connection |
Screw connection |
| Voltage type (supply voltage) |
AC |
| Wall mounting possible |
false |
| Weight |
150g |
| Width |
22.5mm |
| Width in number of modular spacings |
N/A |
