Phoenix Contact 2903706 REL-PR3 Relay 24 V DC 3 NO Pluggable High-Power

The Phoenix Contact industrial relay is designed for reliable switching of electrical devices with a 24 V DC control signal. With a part number of 2903706, this relay module features a compact design suitable for space-limited applications. Typically used in automation systems, it ensures efficient electrical control in industrial environments.

Coil Voltage	24V DC
Contact Configuration	3NO
Complete with socket	false
Degree of protection (IP)	Other
Depth	45.5mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	36.1mm
Material contact	N/A
Material of contact insert	Other
Material of contact surface	Untreated
Max. starting current	N/AA
Misc Attribute	REL-PR3- 24DC/3X1
Mounting Type	Plug-in
Nominal Current	0.07A
Number of contacts as change-over contact	0
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	3
Operating voltage AC 50 Hz	- - -V
Operating voltage AC 60 Hz	- - -V
Operating voltage DC	- - -V
Rated control supply voltage AC 50 Hz	- - -V
Rated control supply voltage AC 60 Hz	- - -V
Rated control supply voltage DC	20.4 - 26.4V
Relay technology category according to IEC 61810-7	N/A
Type	Industrial relay
Type of electric connection	Plug-in connection
Type of switch contact	Single contact
Voltage type (operating voltage)	N/A
Voltage type for actuating	DC
Width	38.6mm
With detachable clamps	false
With forced-guided contacts	false
With LED indication	false
