Phoenix Contact 1452165 Valve Connector 3-Pos Type A 1 LED 230V M16

Phoenix Contact manufactures the valve connector SACC-VB-3CON-M16/A-1L-SV 230V, part number 1452165. This connector provides reliable power transmission at 230 volts, ideal for industrial automation systems. It is commonly used in applications requiring secure electrical connections for solenoid valves and sensors.

Type	SACC-VB-3CON-M16/A-1L-SV 230V
Connectable conductor cross section	0.25 - 1.5mm²
Degree of protection (IP), mounted	IP65
For cable outer diameter	6 - 8mm
Housing Material	Other
Inflammability class of insulation material according to UL94	HB
Material of contact surface	Other
Min. number of insertion cycles	50
Misc Attribute	SACC-VB-3CON-M16/A-1L-SV 230V
Number of Poles	3
Operating Temperature	-25 - 60°C
Pollution degree	3
Rated current	1.5A
Rated voltage	230V
With PE-connection	false
With status indication	true
