Pepperl+Fuchs RL31-8-1200-RT/73C/136 Light Barrier Compact & Robust Design

The Pepperl+Fuchs RL31-8-1200-RT/73C/136 is a retroreflective photoelectric sensor ideal for industrial automation. This light barrier features an M12, 4-pin connection and is designed for precise movement detection and proximity switching. Its typical applications include object detection, counting, and positioning in conveyor systems and production lines.

Type	Retroreflective photo sensor
Wavelength	630nm
Max Range	1.2m
Operating Voltage	30V DC
Outputs	2 x push-pull output
Switching Frequency	N/A
Connection	M12, 4-pin
Connector	M12 (4-pin)
Functions	Light-ON
IP Rating	IP67
Min. operating voltage	10V DC
Misc Attribute	Reflective light sensor (light-switching)
Range	1.2m
