MW Mean Well XDR-480E-48 Power Supply Units Open & DIN 480W 48V

Mean Well XDR-480E-48 is a robust open and DIN rail power supply unit designed for demanding industrial applications. With a rated output power of 480 watts and a nominal output voltage of 48 volts, this power supply module is engineered for reliability and efficiency in various environments. The XDR-480E-48 is suited for installation in industrial automation systems, machinery control panels, and building management systems, where stable and continuous power is essential. Its versatile rail mount design allows for seamless integration within standard DIN rails, enhancing system organisation and space efficiency. This DIN mains unit also features essential safety and protection mechanisms to ensure compliance with rigorous industrial standards.

Type	Rail mounted PSU (DIN)
Number of Outputs	1
Power Rating	480W
Connection	Screw terminal
Content	1
Dimensions	(L x W x H) 125 x 48 x 125.2 mm
Efficiency	96%
Height	125.2mm
IP Rating	Protection class I
Length	125mm
Max. output current	10A
Max. temperature	-40°C
Maximum Input Volage	264V
Maximum Operating Temperature	+70°C
Maximum Temperature	-40°C
Min. temperature	+70°C
Minimum Input Volage	85V
Minimum Operating Temperature	+70°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	10A
Output voltage (max.)	48V
Output voltage (nominal)	48V
Power	480W
Product Type	Rail mounted PSU (DIN)
Width	48mm
