MW Mean Well XDR-480E-12 Open DIN Power Supply Units

Mean Well's XDR-480E-12, also known as part number 3431214, is a robust open and DIN rail power supply unit engineered for industrial applications. This rail mount power supply unit operates efficiently within demanding environments, providing a stable 12 V DC output while supporting electric currents up to 40 A. Designed to fit conveniently onto standard DIN rails, this unit is ideal for compact installation in control cabinets and automation systems. The XDR-480E-12 is particularly suited for use in a variety of sectors including manufacturing automation, process control, and building automation, where reliable DC power supply modules are crucial for the continuous operation of critical systems.

Type	Rail mounted PSU (DIN)
Nominal value output current 1	40A
Number of Outputs	1
Power Rating	480W
Content	1
Depth	125mm
Dimensions (L x W x H)	125 x 48 x 125.2mm
Efficiency	94%
Height	125.2mm
IP Rating	Protection class I
Max. output current 1	30A
Max. temperature	-40°C
Maximum input voltage	264V
Maximum Operating Temperature	+70°C
Maximum Temperature	-40°C
Min. temperature	+70°C
Minimum Input Voltage	85V
Minimum Operating Temperature	+70°C
Nominal value output current 2	40A
Nominal value output current 3	40A
Nominal value output voltage 1	12V
Operating temperature (min.)	-40°C
Output current (max.) - rounded	30A
Output voltage (max.)	12V
Power	360W
Product Type	Rail mounted PSU (DIN)
Type of electric connection	Screw terminal
Width	48mm
