MW Mean Well XDR-150E-36 power supply unit open & DIN mount 3431208

Mean Well's XDR-150E-36 is an open-frame DIN rail power supply unit, designed for industrial applications requiring reliable power delivery. It offers a nominal output of 36 volts and a power rating of 150 watts, making it suitable for use in control panels and automation systems. With its efficient design and ease of installation, the XDR-150E-36 is ideal for environments where space is constrained yet consistent and stable power is crucial. Engineered to fit standard DIN rails, this unit provides a robust solution for integrating power into various industrial control systems. Its versatility makes it an essential component for professionals working in industrial automation, machinery control, and building management systems.

Type	Rail mounted PSU (DIN)
Number of Outputs	1
Power Rating	150W
Connection	Screw terminal
Content	1
Dimensions	(L x W x H) 116 x 30 x 125.2 mm
Efficiency	91%
Height	125.2mm
IP Rating	Protection class I
Length	116mm
Max. output current	4.33A
Max. temperature	-40°C
Maximum Input Volage	264V
Maximum Operating Temperature	+70°C
Maximum Temperature	-40°C
Min. temperature	+70°C
Minimum Input Volage	85V
Minimum Operating Temperature	+70°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	4.33A
Output voltage (max.)	36V
Output voltage (nominal)	36V
Power	155.9W
Product Type	Rail mounted PSU (DIN)
Width	30mm
