Metrix MX5060 Multimeter Bench Digital/Analogue CAT III 1000V 60000 Counts

The Metrix MX 5060 is a versatile bench multimeter that combines digital and analogue functions, providing precise readings with a display resolution of 60,000 counts. Designed for high-performance applications, this CAT III 1000 V multimeter is ideal for measuring voltage, current, and frequency in both professional and laboratory settings. Manufactured by Metrix, it serves as a reliable tool for engineers and technicians requiring accurate and comprehensive electrical measurements.

Type	Bench multimeter
A AC reading range (min.)	6000µA
A DC reading range (max.)	20A
Amperage reading range AC (max.)	20A
Amperage reading range DC (min.)	6000µA
Calibrated to	Manufacturer's standards (no certificate)
Dim	(L x W x H) 95 x 295 x 295 mm
Display (counts)	60000
Frequency reading range	60 Hz to 60kHz
Height	295mm
Interfaces	USB
Length	95mm
Misc Attribute	MX 5060
Reading category	CAT III 1000 V
Reading range - capacity	6 nF to 60mF
Reading range - resistance	600 Ω to 60 MΩ
Temperature	-200 °C to +1200°C
V AC reading range (max.)	1000V
V AC reading range (min.)	60mV
Voltage DC reading range (max.)	1000V
Voltage reading range DC (min.)	60mV
Width	295mm
