Mean Well UHP-350-12 350.4W 12.6V 29.2A high-efficiency low-profile PSU

The Mean Well UHP-350-12 is a switch mode power supply unit (SMPSU) with a DC output of 12.6 V and a current rating of 29.2 A, providing a total power output of 350.4 W. It features a PCB mount design with screw terminals, making it suitable for circuit board equipping and easy installation. Typical applications include industrial automation, electronics assembly, and other situations requiring efficient and reliable power conversion on printed circuit boards.

Type	SMPSU
Connection	Screw terminal
Dim	(L x W x H) 220 x 62 x 31 mm
Height	31mm
Input voltage (max.)	264V AC
Length	220mm
Max. output current	29.2A
Max. temperature	70°C
Min. input voltage	90V AC
Min. temperature	-30°C
Misc Attribute 1	UHP-350-12
Misc Attribute 2	closed
No. of outputs	1
Operating temperature (max.)	70°C
Operating temperature (min.)	-30°C
Output current (max.) - rounded	29.2A
Output voltage (max.)	12.6V DC
Output voltage (min.)	11.4V DC
PFC	Yes
Power	350.4W
PSU features	Adjustable voltage output
Weight	680g
Width	62mm
