Mean Well SPBW06G-05 DC/DC converter 1.2 A 6 W 1 output 1500 V DC insulation

Mean Well
Order Code:

05-1851

Brand: Mean Well MPN: SPBW06G-05 EAN-13: 4021087040860
Qty Unit Price (Ex VAT)
1+ £8.69
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well SPBW06G-05 is a DC/DC converter module with a 6 W power rating and a current output of 1.2 A. It has a single output and is suitable for applications requiring efficient power conversion. Typical uses include powering electronic devices where stable direct current is needed.
Connection Pins
Dim (L x W x H) 21.8 x 9.2 x 11.1 mm
Efficiency (max.) 85%
Height 11.1mm
Input voltage (max.) 75V DC
Insulation Voltage 1500V DC
Length 21.8mm
Max. output current 1.2A
Min. input voltage 18V DC
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1.2A
Output voltage (max.) 5V DC
Power 6W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 9.2mm
