Mean Well SPBW06F-15 DC/DC converter 6W 400mA 1 output -40 to +90°C

Mean Well
Order Code:

05-1849

Brand: Mean Well MPN: SPBW06F-15 EAN-13: 4021087040884
Qty Unit Price (Ex VAT)
1+ £12.33
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well SPBW06F-15 is a DC/DC converter module designed to provide a single output with a current rating of 400 mA and a power capacity of 6 W. This module is ideal for applications requiring efficient voltage conversion and stabilisation in compact spaces. It is often used in electronics where consistent DC voltage is essential, such as telecommunications equipment and industrial control systems.
Connection Pins
Dim (L x W x H) 21.8 x 9.2 x 11.1 mm
Efficiency (max.) 88%
Height 11.1mm
Input voltage (max.) 36V DC
Insulation Voltage 1500V DC
Length 21.8mm
Max. output current 400mA
Min. input voltage 9V DC
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 400mA
Output voltage (max.) 15V DC
Power 6W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 9.2mm
