Mean Well SKMW30F-03 dc/dc converter 7.5A 30W 1 output 1pc 4:1 input range

Mean Well
Order Code:

05-1772

Brand: Mean Well MPN: SKMW30F-03 EAN-13: 4021087041379
Qty Unit Price (Ex VAT)
1+ £36.68
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

Mean Well manufactures the SKMW30F-03, a DC/DC converter rated at 7.5 A with a power output of 30 W. This converter provides one output, making it ideal for specific electronic applications requiring stable power supply conversion. Its typical uses include powering sensitive electronics in industrial and telecommunications environments.
Connection Pins
Dim (L x W x H) 25.4 x 25.4 x 10.2 mm
Efficiency (max.) 88%
Height 10.2mm
Input voltage (max.) 36V DC
Insulation Voltage 1500V DC
Length 25.4mm
Max. output current 7.5A
Min. input voltage 9V DC
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 7.5A
Output voltage (max.) 3.3V DC
Power 30W
PSU features DC-to-DC converter
Type DC/DC converter
Width 25.4mm
