Mean Well SFTN02N-12 DC/DC converter 2W 167mA 1 output module 1pc

Mean Well
Standard range
Order Code:

05-1726

Brand: Mean Well MPN: SFTN02N-12
Qty Unit Price (Ex VAT)
1+ £4.25
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
7 in stock, despatched in 4 working days

The Mean Well SFTN02N-12 is a DC/DC converter module with a single output delivering up to 167 mA and 2 W of power. It is ideal for applications requiring reliable voltage conversion with a compact design. This converter is commonly used in electronics projects and industrial automation systems for efficient power management.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 79%
Height 7.1mm
Input voltage (max.) 26.4V DC
Insulation voltage 3000V DC
Length 15.24mm
Max. output current 167mA
Min. input voltage 21.6V DC
Misc Attribute SFTN02N-12
No. of outputs 1
Operating temperature (max.) +100°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 167mA
Output current (min.) 33mA
Output voltage (max.) 12V DC
Power 2W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 1.2g
Width 10.9mm
