Mean Well SFTN02M-05 DC/DC converter module 400mA 2W 1 output

Mean Well
Standard range
Order Code:

05-1722

Brand: Mean Well MPN: SFTN02M-05
Qty Unit Price (Ex VAT)
1+ £4.37
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well SFTN02M-05 is a DC/DC converter module with a current rating of 400 mA and power output of 2 W, featuring one output. It is suitable for applications requiring efficient voltage conversion in electronic circuits, such as for boards or embedded systems. This converter provides reliable performance for powering various electronic devices with consistent direct current.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 80%
Height 7.1mm
Input voltage (max.) 13.2V DC
Insulation voltage 3000V DC
Length 15.24mm
Max. output current 400mA
Min. input voltage 10.8V DC
Misc Attribute SFTN02M-05
No. of outputs 1
Operating temperature (max.) +100°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 400mA
Output current (min.) 40mA
Output voltage (max.) 5V DC
Power 2W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 1.2g
Width 10.9mm
