Mean Well SCWN03E-15 SCWN03 3W DC/DC converter -40 to +90°C 3000VDC insul.

Mean Well
Standard range
Order Code:

05-1657

Brand: Mean Well MPN: SCWN03E-15
Qty Unit Price (Ex VAT)
1+ £6.56
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1 in stock, despatched in 4 working days

The Mean Well SCWN03E-15 is a DC/DC converter module providing a single output with a power rating of 3 W and a current capacity of 200 mA. Designed for high-efficiency power conversion, it is suitable for applications requiring reliable direct current voltage transformation. This compact module is ideal for embedded systems, industrial electronics, and other low-power electronic devices.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 81%
Height 10.2mm
Input voltage (max.) 9V DC
Insulation voltage 3000V DC
Length 31.8mm
Max. output current 200mA
Min. input voltage 4.5V DC
Misc Attribute SCWN03E-15
No. of outputs 1
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 200mA
Output voltage (max.) 15V DC
Power 3W
PSU features DC-to-DC converter
Weight 12.5g
Width 20.3mm
