Mean Well RSP-200-12 SMPSU 12V 16.7A 200W Enclosed PFC protections

Mean Well
Order Code:

05-1585

Brand: Mean Well MPN: RSP-200-12 EAN-13: 4021087014137
Qty Unit Price (Ex VAT)
1+ £46.39
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well RSP-200-12 is a switch-mode power supply unit delivering 12 V DC at 16.7 A with a total output of 200 W. This PCB-mounted power supply is equipped with screw terminals and is well-suited for applications requiring a reliable and compact power source. Typical uses include industrial automation equipment, electronic testing systems, and other demanding environments requiring steady DC output.
Output Voltage 12 V DC
Connection Screw terminal
Dim (L x W x H) 215.00 x 115.00 x 30.00 mm
Height 30.00mm
Input voltage (max.) 264V AC
Length 215.00mm
Max. output current 16.7A
Min. input voltage 90V AC
Misc Attribute 1 Synchronised
Misc Attribute 3 closed
Number of Inputs 1
Number of Outputs 1
Output current (details) 16.7 A
Output current (max.) - rounded 16.7A
Output current (min.) 0A
Output voltage (max.) 12V DC
Output voltage (min.) 12V DC
Power 200W
Type SMPSU
Width 115.00mm
