Mean Well RSDW20H-15 DC/DC converter 1.33A 20W single output

Mean Well
Order Code:

05-1566

Brand: Mean Well MPN: RSDW20H-15 EAN-13: 4021087048217
Qty Unit Price (Ex VAT)
1+ £31.57
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

Mean Well's RSDW20H-15 is a DC/DC converter with a single output, rated at 1.33 A and 20 W. This converter is ideal for applications requiring stable voltage conversion in industrial or telecommunications settings. Its compact design makes it suitable for use in space-constrained environments, providing reliable direct current rectification.
Connection Pins
Dim (L x W x H) 50.8 x 25.4 x 10.2 mm
Efficiency (max.) 89.5%
Height 10.2mm
Input voltage (max.) 160V DC
Insulation Voltage 3000V DC
Length 50.8mm
Max. output current 1.33A
Min. input voltage 43V DC
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1.33A
Output voltage (max.) 15V DC
Power 20W
PSU features DC-to-DC converter
Type DC/DC converter
Width 25.4mm
