Mean Well RSDW20H-12 RSDW Series DC/DC converter 1.67 A 20 W 1 output

Mean Well
Order Code:

05-1565

Brand: Mean Well MPN: RSDW20H-12 EAN-13: 4021087048224
Qty Unit Price (Ex VAT)
1+ £31.57
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well RSDW20H-12 is a DC/DC converter that provides a single output with 1.67 Amps and 20 Watts of power. It is ideal for applications that require reliable and efficient power conversion. This device is commonly used in industrial and telecommunications equipment.
Connection Pins
Dim (L x W x H) 50.8 x 25.4 x 10.2 mm
Efficiency (max.) 90%
Height 10.2mm
Input voltage (max.) 160V DC
Insulation Voltage 3000V DC
Length 50.8mm
Max. output current 1.67A
Min. input voltage 43V DC
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1.67A
Output voltage (max.) 12V DC
Power 20W
PSU features DC-to-DC converter
Type DC/DC converter
Width 25.4mm
