Mean Well RSDW20F-12 dc/dc converter 1.67 A 20 W single output

Mean Well
Order Code:

05-1558

Brand: Mean Well MPN: RSDW20F-12 EAN-13: 4021087048293
Qty Unit Price (Ex VAT)
1+ £31.57
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well RSDW20F-12 is a DC/DC converter with a current rating of 1.67 A and a power output of 20 W, featuring a single output. It is designed for efficient power conversion in industrial and telecommunications applications. The unit is renowned for its compact form factor and reliable performance.
Connection Pins
Dim (L x W x H) 50.8 x 25.4 x 10.2 mm
Efficiency (max.) 90%
Height 10.2mm
Input voltage (max.) 36V DC
Insulation Voltage 1500V DC
Length 50.8mm
Max. output current 1.67A
Min. input voltage 9V DC
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1.67A
Output voltage (max.) 12V DC
Power 20W
PSU features DC-to-DC converter
Type DC/DC converter
Width 25.4mm
