Mean Well RSDW08F-12 DC/DC converter 666mA 8W 1-output module

Mean Well
Standard range
Order Code:

05-1546

Brand: Mean Well MPN: RSDW08F-12
Qty Unit Price (Ex VAT)
1+ £21.40
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
3 in stock, despatched in 4 working days

The Mean Well RSDW08F-12 is a DC/DC converter module with a single output, providing 666 mA and 8 W power capacity. It is suitable for applications requiring voltage conversion in electronic systems where consistent direct current is needed. Typical uses include embedded systems, telecommunications, and industrial control circuits.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 85%
Height 10.2mm
Input voltage (max.) 36V DC
Insulation voltage 1500V DC
Length 31.8mm
Max. output current 666mA
Min. input voltage 9V DC
Misc Attribute RSDW08F-12
No. of outputs 1
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 666mA
Output voltage (max.) 12V DC
Power 8W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 18.4g
Width 20.3mm
