Mean Well RPS-200-48 Series SMPSU 48V DC 4.2A 201.6W medical-grade

The Mean Well RPS-200-48 SMPSU is a 48 V DC power supply unit by Mean Well, providing a current rating of 4.2 A and a power output of 201.6 W. It is a printed circuit board (PCB) mounted power supply with solder lugs, suitable for equipping PCBs where efficient power conversion is needed. Typical applications include industrial electronics and automation systems requiring reliable DC power supply options.

Type	SMPSU
Nominal value output current 1	4.2A
Number of Outputs	1
Power Rating	200W
Depth	101.6mm
Dimensions (L x W x H)	101.6 x 50.8 x 29mm
Height	29mm
Max. output current 1	4.2A
Maximum Temperature	+70°C
Min. temperature	-30°C
Misc Attribute 2	Pulsed
Misc Attribute 3	open
MTBF	500200h
Nominal value output voltage 1 [DC]	48V
Number of Inputs	1
PFC	No
Type of electric connection	Pin strip for nylon crimp connectors
Weight	190g
Width	50.8mm
