Mean Well RPS-120-24 SMPSU 24V DC 5A 120W Output Power Supply

The Mean Well RPS-120-24 SMPSU is a switch mode power supply unit delivering 24 V DC at a current of 5 A, with a total power output of 120 W. It is designed for PCB mounting with solder lugs, ideal for applications requiring reliable power from compact circuit board installations. Typical applications include industrial equipment and automation systems where efficient power conversion is essential.

Type	SMPSU
Nominal value output current 1	5A
Number of Outputs	1
Power Rating	120W
Depth	101.6mm
Dimensions (L x W x H)	101.6 x 50.8 x 29mm
Height	29mm
Max. output current 1	5A
Maximum Temperature	+70°C
Min. temperature	-30°C
Misc Attribute 2	Pulsed
Misc Attribute 3	open
MTBF	653500h
Nominal value output voltage 1 [DC]	24V
Number of Inputs	1
PFC	No
Type of electric connection	Pin strip for nylon crimp connectors
Weight	150g
Width	50.8mm
