Mean Well RDDW20F-05 DC/DC converter 20W 2 outputs 2A

Mean Well
Standard range
Order Code:

05-1433

Brand: Mean Well MPN: RDDW20F-05
Qty Unit Price (Ex VAT)
1+ £31.51
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
3 in stock, despatched in 4 working days

The Mean Well RDDW20F-05 is a DC/DC converter that supports two outputs with a total power of 20 W and a current rating of 2 A. This component is typically used in applications requiring efficient power conversion, such as in industrial and telecommunications equipment. It is designed for integration into printed circuit boards to provide stable and reliable voltage conversion.
Type DC/DC converter
Connection Pins
Dim (L x W x H) 50.8 x 25.4 x 10.2 mm
Efficiency (max.) 89%
Height 10.2mm
Input voltage (max.) 36V DC
Insulation voltage 1500V DC
Length 50.8mm
Max. output current 2A
Min. input voltage 9V DC
Misc Attribute RDDW20F-05
No. of outputs 2
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 2A
Power 20W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 35g
Width 25.4mm
