Mean Well RDDW10H-15 DC/DC converter 333 mA 10 W 2 outputs 1 pc

Mean Well
Order Code:

05-1432

Brand: Mean Well MPN: RDDW10H-15 EAN-13: 4021087048620
Qty Was Unit Price (Ex VAT)
1+ £23.22 £20.13
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
4 available to back orderBack-order availability date - 08/01/2026

The Mean Well RDDW10H-15 is a DC/DC converter featuring two outputs, each delivering a current of 333 mA and a total power of 10 W. This converter is ideal for applications requiring the conversion of direct current voltages with high efficiency. It is commonly used in industrial and telecommunications equipment, ensuring reliable power delivery.
Input Voltage Range 160V DC
Output Current 333mA
Number of Outputs 2
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 12.7 mm
Efficiency (max.) 88%
Height 12.7mm
Insulation Voltage 3000V DC
Length 31.8mm
Max. output current 333mA
Min. input voltage 43V DC
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Power 10W
PSU features DC-to-DC converter
Type DC/DC converter
Width 20.3mm
