Mean Well PWM-60-24 LED driver 60W 24V DC dimmable IP67 waterproof

Mean Well
Order Code:

05-1405

Brand: Mean Well MPN: PWM-60-24 EAN-13: 4021087025539
Qty Unit Price (Ex VAT)
1+ £36.96
5+ £35.11
10+ £33.89
25+ £32.89
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well PWM-60-24 LED driver is a constant voltage and current LED transformer delivering 60 W, 2.5 A at 24 V DC. It features a dimmable output with a PFC circuit and surge protection, making it ideal for LED applications such as lighting and LED strips. Its robust design ensures reliable power supply for LED installations.
Type LED driver
Output Voltage 36 V
Connection Open end cable
Dim (L x W x H) 150 x 53 x 35 mm
Height 35mm
Input voltage (max.) 305V AC
IP Rating IP67
Length 150mm
Max. output current 2.5A
Max. power 60W
Min. input voltage 90V AC
Misc Attribute 1 switched-mode
Misc Attribute 2 Synchronised
Misc Attribute 3 PWM
Number of Inputs 1
Number of Outputs 1
Output current (details) 1.67A
Output current (max.) - rounded 2.5A
Output voltage (max.) 24V DC
Power range 60 W (max)
Protection Class IP67
Test mark EN61000-3-2 Class C
Width 53mm
