Mean Well PWM-120-24BLE LED driver 24V 120W dimmable surge protect

Mean Well
Order Code:

05-1385

Brand: Mean Well MPN: PWM-120-24BLE EAN-13: 4021087070324
Qty Unit Price (Ex VAT)
1+ £129.10
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well PWM-120-24BLE LED driver delivers a constant voltage of 24 V DC, with a power output of 120 W and a current of 5 A, and is suitable for flammable surfaces. It features dimmable capabilities, a power factor correction circuit, surge protection, and is approved for use on furniture and outdoor installations. Typical applications include powering LED strips and other LED lighting solutions.
Type LED driver
Connection Open end cable
Dim (L x W x H) 191 x 63 x 37.5 mm
Factory colour Anthracite/black
Height 37.5mm
IP Rating IP67
Length 191mm
Max. output current 5A
Max. power 120W
Max. temperature +90°C
Min. temperature -25°C
Misc Attribute Constant voltage
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 5A
Output voltage (max.) 24V DC
Power range 120 W (max)
Protection Class II
Test mark CE · MM · SELV
Width 63mm
