Mean Well Pcd-40-350B LED Driver Constant Current 40W 0.35A 70-108V DC Dimmable

Mean Well PCD-40-350B is a reliable LED driver designed for constant current applications, providing an output power of 40 watts at 0.35 amperes and a voltage range between 70 and 108 volts DC. This dimmable driver incorporates a PFC (power factor correction) circuit and surge protection, making it suitable for use in varying electrical environments. It is engineered for installation on flammable surfaces, adhering to safety standards. Common applications include architectural lighting, retail display lights, and other environments requiring efficient and controllable LED lighting solutions. The robust construction and technical features ensure it meets the demanding needs of professional lighting projects.

Type	LED driver
Output Voltage	70V DC
Output Current	40 W (max)
Input Voltage	230V AC
Connection	Open end cable
Dimensions	(L x W x H) 128 x 60 x 31.5 mm
Height	31.5mm
IP Rating	IP30
Length	128mm
Max. output current	0.35A
Max. power	40W
Min. input voltage	180V AC
No. of Inputs	1
No. of outputs	1
Protection Class	II
Weight	230g
Width	60mm
