Mean Well MSP-1000-24 SMPSU 28V DC 42A 1008W efficient power supply

The Mean Well MSP-1000-24 is a switch-mode power supply unit that delivers 28 V DC at 42 A, providing a total output of 1008 W. It is designed for PCB mounting and features screw terminals for secure connections. These units are commonly used in industrial automation, telecommunications, and LED lighting applications where robust and reliable power supply is essential.

Output Voltage	22V DC
Output Current	42A
Power Rating	1008W
Number of Outputs	1
Input Voltage	180-264VAC
Connection	Screw terminal
Dimensions	(L x W x H) 218 x 105 x 63.5 mm
Height	63.5mm
Length	218mm
Maximum Operating Temperature	+70°C
Misc Attribute 2	Pulsed
Misc Attribute 3	closed
MTBF	286300h
Operating temperature (min.)	-40°C
PFC	Yes
Type	SMPSU
Weight	1530g
Width	105mm
