Mean Well MPM-20-15 MPM series AC/DC PSU 15V DC 1.4A for medical devices

Mean Well
Standard range
Order Code:

05-1173

Brand: Mean Well MPN: MPM-20-15
Qty Unit Price (Ex VAT)
1+ £12.52
5+ £12.14
10+ £11.77
25+ £11.40
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well MPM-20-15 is a PCB-mounted AC/DC power supply unit with a 15 V DC output and a current rating of 1.4 A, delivering up to 21 W of power. This compact power supply features solder lugs for easy connection and is typically used in applications such as industrial control, telecommunications, and automation systems. It is ideal for equipping printed circuit boards in environments requiring efficient and reliable power conversion.
Type AC/DC PSU (print)
Connection Pins
Dim (L x W x H) 52.4 x 27.2 x 24 mm
Efficiency to 87%
Height 24mm
Input frequency 47-440Hz
Input voltage (max.) 264V AC
Length 52.4mm
Max. output current 1.4A
Min. input voltage 80V AC
Misc Attribute 1 MPM-20-15
Misc Attribute 2 Pulsed
No. of outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -35°C
Output current (max.) - rounded 1.4A
Output current 1 1.4A
Output voltage (max.) 15V DC
Output voltage 1 15V DC
Power 21W
Protection class II
Residual ripple 180 mVpp
Tolerance (output voltage) ±1,5%
Weight 56g
Width 27.2mm
