Mean Well MPM-15-5 AC/DC PSU 5V DC 3A 15W medical approved compact design

Mean Well
Order Code:

05-1171

Brand: Mean Well MPN: MPM-15-5 EAN-13: 4021087048842
Qty Unit Price (Ex VAT)
1+ £11.43
5+ £11.09
10+ £10.75
25+ £10.40
50+ £10.06
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well MPM-15-5 is an AC/DC power supply unit designed for PCB mounting. It provides a DC output of 5 V and 3 A, with a power rating of 15 W. Typical applications include powering small electronic devices or projects requiring a reliable and compact power source.
Connection Pins
Dim (L x W x H) 52.4 x 27.2 x 24 mm
Efficiency to 85,5%
Height 24mm
Input Frequency 47-440Hz
Input voltage (max.) 264V AC
Length 52.4mm
Max. output current 3A
Min. input voltage 80V AC
Misc Attribute 2 Pulsed
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 3A
Output Current 1 3A
Output voltage (max.) 5V DC
Output Voltage 1 5V DC
Power 15W
Protection Class II
Residual ripple 150 mVpp
Tolerance (output voltage) ±1,5%
Type AC/DC PSU (print)
Width 27.2mm
