Mean Well MPM-15-12 AC/DC PSU 12V 1.25A 15W compact with high efficiency

Mean Well
Order Code:

05-1167

Brand: Mean Well MPN: MPM-15-12 EAN-13: 4021087048880
Qty Unit Price (Ex VAT)
1+ £10.92
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well MPM-15-12 is a PCB mount power supply unit featuring AC/DC conversion with a 12 V DC output, capable of delivering up to 1.25 A at 15 W. It is equipped with solder lugs and is ideal for compact circuit board applications where efficient power management is required. Suitable for industrial automation, instrumentation, and other electronic equipment requiring reliable power.
Connection Pins
Dim (L x W x H) 52.4 x 27.2 x 24 mm
Efficiency to 86,5%
Height 24mm
Input Frequency 47-440Hz
Input voltage (max.) 264V AC
Length 52.4mm
Max. output current 1.25A
Min. input voltage 80V AC
Misc Attribute 2 Pulsed
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1.25A
Output Current 1 1.25A
Output voltage (max.) 12V DC
Output Voltage 1 12V DC
Power 15W
Protection Class II
Residual ripple 150 mVpp
Tolerance (output voltage) ±1,5%
Type AC/DC PSU (print)
Width 27.2mm
