Mean Well MFM-10-5 ac/dc psu 5 v dc 2 a 10 w medical grade low leakage

Mean Well
Standard range
Order Code:

05-1149

Brand: Mean Well MPN: MFM-10-5
Qty Unit Price (Ex VAT)
1+ £10.90
5+ £10.57
10+ £10.25
25+ £9.79
50+ £9.49
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
17 in stock, despatched in 4 working days

Mean Well's MFM-10-5 is an AC/DC printed circuit board power supply unit offering a 5 V DC output at 2 A, with a total power rating of 10 W. This PCB-mounted power supply features solder lugs for connectivity, making it ideal for integration into electronic devices and equipment requiring reliable DC power conversion. Typical applications include powering small electronic circuits and devices where a compact and efficient power supply is necessary.
Type AC/DC PSU (print)
Dim (L x W x H) 42 x 22.3 x 20.5 mm
Height 20.5mm
Input voltage (max.) 264V AC
Length 42mm
Max. output current 2A
Max. temperature 85°C
Min. input voltage 80V AC
Min. temperature -30°C
Misc Attribute 1 MFM-10-5
Misc Attribute 2 Pulsed
Misc Attribute 3 open
MTBF 1756000h
No. of inputs 1
No. of outputs 1
Output current (max.) - rounded 2A
Output voltage (max.) 5V DC
PFC No
Power 10W
Weight 18g
Width 22.3mm
