Mean Well MDS01N-12 DC/DC converter 84 mA 1 W 1 output medical-grade

Name: Mean Well MDS01N-12 DC/DC converter 84 mA 1 W 1 output medical-grade
Brand: Mean Well
Price: 5.86 GBP
Availability: InStock

Standard range

Order Code:

05-1136

Brand: Mean Well MPN: MDS01N-12

RoHS Compliant
Country of Origin: China
Free UK shipping available
View Full Product Range (16)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£5.86

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

2 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

The Mean Well MDS01N-12 is a DC/DC converter module capable of delivering 84 mA at 1 W with a single output. This component is ideal for applications requiring efficient power conversion in a compact form factor. It is commonly used in electronic devices requiring stable and isolated power supply solutions.

Type	DC/DC converter (module)
Connection	Pins
Dim	(L x W x H) 19.5 x 9.8 x 12.5 mm
Efficiency (max.)	79%
Height	12.5mm
Input voltage (max.)	26.4V DC
Length	19.5mm
Max. output current	84mA
Min. input voltage	21.6V DC
Misc Attribute	MDS01N-12
No. of outputs	1
Operating temperature (max.)	+85°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	84mA
Output current (min.)	9mA
Output voltage (max.)	12V DC
Power	1W
PSU features	DC-to-DC converter
Weight	4.2g
Width	9.8mm
