Mean Well MDR-40-5 PSU DIN Rail 5V 6A 30W Enclosed Overload Protection

Mean Well
Standard range
Order Code:

05-1123

Brand: Mean Well MPN: MDR-40-5
Qty Unit Price (Ex VAT)
1+ £17.94
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
73 in stock, despatched in 4 working days

The Mean Well MDR-40-5 is a rail mounted power supply unit designed for industrial applications. It delivers a 5 V DC output at 6 A with a total power of 30 W, featuring a single output channel. Its enclosed design and DIN rail mounting make it suitable for compact and efficient power distribution in control panels and automation systems.
Type Rail mounted PSU (DIN)
Connection Screw terminal
Dim (L x W x H) 40.00 x 90.00 x 100.00 mm
Height 100.00mm
Input voltage (max.) 264V AC
Length 40.00mm
Manufacturer part # MDR-40-5
Max. output current 6A
Min. input voltage 90V AC
Misc Attribute 1 Synchronised
Misc Attribute 2 MDR-40-5
No. of inputs 1
No. of outputs 1
Output current (details) 6 A
Output current (max.) - rounded 6A
Output voltage 5 V DC
Output voltage (max.) 5V DC
Output voltage (nominal) 5V DC
Power 30W
Weight 300.00g
Width 90.00mm
