Mean Well Lpf-40-48 LED Driver 40W 0.84A 28.8-48V DC Pfc Surge Protection

Mean Well LPF-40-48 LED Driver is a robust and reliable solution for powering LED systems, with a manufacturer part number of 1293686. This device functions as an LED driver that ensures a stable constant voltage and current, capable of delivering up to 40 watts at 0.84 amperes across a range of 28.8 to 48 volts DC. It incorporates a power factor correction (PFC) circuit and built-in surge protection to safeguard LED installations from electrical disturbances. The unit is not dimmable, making it ideal for applications where a consistent light output is required, such as in industrial and commercial lighting systems. Its design focuses on reliability in challenging electrical environments, contributing to its suitability for architects and engineers developing fixed output lighting installations.

Type	LED driver
Output Voltage	28.8V DC
Output Current	40 W (max)
Input Voltage	277V AC
Connection	Open end cable
Dimensions	(L x W x H) 162.50 x 42.50 x 32.00 mm
Height	32.00mm
IP Rating	IP67
Length	162.50mm
Max. output current	0.84A
Max. power	40W
Min. input voltage	90V AC
No. of Inputs	1
No. of outputs	1
Protection Class	II
Weight	450.00g
Width	42.50mm
