Mean Well LPF-25D-36 LPF-25D LED driver 25.2W 0.7A 36V IP67 dimmable

Mean Well
Order Code:

05-1028

Brand: Mean Well MPN: LPF-25D-36 EAN-13: 4021087007672
Qty Unit Price (Ex VAT)
1+ £24.96
5+ £23.72
10+ £22.87
25+ £22.25
50+ £21.11
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

Mean Well's LPF-25D-36 LED driver is a constant current and constant voltage LED transformer offering 25.2 watts of power and a maximum current of 0.7 amps, with a voltage range of 19.8 - 36 V DC. It features a dimmable function, power factor correction (PFC) circuit, and surge protection for enhanced safety and reliability. Ideal for LED strips and lighting applications, this driver ensures efficient power delivery with open-ended cable connections
Type LED driver
Connection Open end cable
Dim (L x W x H) 148.00 x 40.00 x 32.00 mm
Height 32.00mm
Input voltage (max.) 305V AC
IP Rating IP67
Length 148.00mm
Max. output current 0.7A
Max. power 25.2W
Min. input voltage 90V AC
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 700mA
Output voltage (max.) 36V DC
Output voltage (min.) 19.8V DC
Power range 25.2 W (max)
Protection Class II
Width 40.00mm
