Mean Well IRM-03-9 PSU 9V 333mA 3W compact low power IoT-friendly

Mean Well
Order Code:

05-0933

Brand: Mean Well MPN: IRM-03-9 EAN-13: 4021087034524
Qty Unit Price (Ex VAT)
1+ £5.90
5+ £5.71
10+ £5.55
25+ £5.35
50+ £5.11
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
46 in stock, despatched in 4 working days

The Mean Well IRM-03-9 is a compact AC/DC power supply unit designed for printed circuit boards. It provides a steady 9 V DC output with a current rating of 333 mA and a power capability of 3 W. This PSU is ideal for applications requiring small form factor and reliable power delivery on PCBs with solder lug connections.
Connection Pins
Consumption (standby) 75mW
Dim (L x W x H) 33.7 x 22.2 x 15 mm
Efficiency to 77%
Height 15mm
Input Frequency 47-63Hz
Input voltage (max.) 305V AC
Length 33.7mm
Max. output current 333mA
Min. input voltage 85V AC
Number of Outputs 1
Operating Temperature -30°C to +85°C
Operating temperature (max.) +85°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 333mA
Output voltage (max.) 9V DC
Power 3W
Protection Class II
Residual ripple 100 mVp-p
Tolerance (output voltage) ±2.5%
Type AC/DC PSU (print)
Width 22.2mm
