Mean Well IRM-02-9S compact AC/DC PSU 9V 222mA 2W IoT automation ready

Mean Well
Order Code:

05-0924

Brand: Mean Well MPN: IRM-02-9S EAN-13: 4021087034630
Qty Unit Price (Ex VAT)
1+ £6.04
5+ £5.85
10+ £5.69
25+ £5.49
50+ £5.31
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 25/12/2025

The Mean Well IRM-02-9S is a PCB mount AC/DC power supply unit rated for 9 V DC output at 222 mA, delivering 2 W. Designed for efficient PCB equipping with solder lugs, it is ideal for applications requiring compact and reliable power solutions. This power supply is suitable for use in various electronic devices and industrial applications requiring stable DC output.
Number of Outputs 1
Output Power Max 2W
Output Voltage 9V DC
Output Current 222mA
Dimensions (L x W x H) 33.7 x 22.2 x 15 mm
Connection SMD
Consumption (standby) 75mW
Efficiency to 72%
Height 15mm
Input Frequency 47-63Hz
Input Voltage 305V AC
Length 33.7mm
Max. output current 222mA
Min. input voltage 85V AC
Operating Temperature -30°C to +85°C
Operating temperature (max.) +85°C
Operating temperature (min.) -30°C
Protection Class II
Residual ripple 150 mVp-p
Tolerance (output voltage) ±2.5%
Type AC/DC PSU (print)
Width 22.2mm
