Mean Well IRM-02-3.3S low-power 3.3V 600mA AC/DC PSU compact and efficient

Mean Well
Order Code:

05-0920

Brand: Mean Well MPN: IRM-02-3.3S EAN-13: 4021087034678
Qty Unit Price (Ex VAT)
1+ £8.31
5+ £8.03
10+ £7.80
25+ £7.74
50+ £7.68
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well IRM-02-3.3S is an AC/DC printed circuit board power supply unit with a 3.3 V DC output and 600 mA current capability. It delivers a total power of 2 W, suitable for small electronic applications that require reliable and efficient power conversion. Typically used in industrial controls, automation systems, and instrumentation, this PSU can be mounted directly on a PCB with solder lugs for secure connections.
Connection SMD
Consumption (standby) 75mW
Dim (L x W x H) 33.7 x 22.2 x 15 mm
Efficiency to 66%
Height 15mm
Input Frequency 47-63Hz
Input voltage (max.) 305V AC
Length 33.7mm
Max. output current 600mA
Min. input voltage 85V AC
Number of Outputs 1
Operating Temperature -30°C to +85°C
Operating temperature (max.) +85°C
Operating temperature (min.) -30°C
Output current (max.) - rounded 600mA
Output voltage (max.) 3.3V DC
Power 2W
Protection Class II
Residual ripple 150 mVp-p
Tolerance (output voltage) ±2.5%
Type AC/DC PSU (print)
Width 22.2mm
