Mean Well HRPG-1000-24 PSU 28V 42A 1008W single-output reliable power

Mean Well
Order Code:

05-0889

Brand: Mean Well MPN: HRPG-1000-24 EAN-13: 4021087047555
Qty Unit Price (Ex VAT)
1+ £229.73
5+ £222.60
10+ £215.71
25+ £206.75
50+ £199.85
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

Mean Well manufactures the HRPG-1000-24 SMPSU, a switch-mode power supply unit delivering 28 V DC at 42 A with a total output of 1008 W. This power supply unit features screw terminals for easy installation and integration into various systems. It is ideal for use in printed circuit board power supply applications, offering reliable performance for industrial and commercial settings.
Connection Screw terminal
Dim (L x W x H) 218 x 105 x 63.5 mm
Height 63.5mm
Input voltage (max.) 264V AC
Length 218mm
Max. output current 42A
Max. temperature +70°C
Min. input voltage 90V AC
Min. temperature -40°C
Misc Attribute 2 closed
Misc Attribute 3 Pulsed
MTBF 228600h
Number of Outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 42A
Output current (min.) 0A
Output voltage (max.) 28V DC
Output voltage (min.) 22V DC
PFC Yes
Power 1008W
PSU features Adjustable voltage output
Type SMPSU
Width 105mm
