Mean Well HRP-300-24 SMPSU 24V 14A 336W compact surge-proof PFC protected

Mean Well
Standard range
Order Code:

05-0885

Brand: Mean Well MPN: HRP-300-24
Qty Unit Price (Ex VAT)
1+ £64.14
5+ £62.22
10+ £60.29
25+ £58.36
50+ £56.44
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
45 in stock, despatched in 4 working days

The Mean Well HRP-300-24 is a switched-mode power supply unit (SMPSU) providing 24 V DC and outputting 14 A, with a power capacity of 336 W. It features a PCB mount design with solder lugs and screw terminals, making it suitable for equipping printed circuit boards with robust power requirements. This power supply is typically used in industrial automation, control systems, and telecommunications applications.
Type SMPSU
Connection Screw terminal
Dim (L x W x H) 199 x 105 x 41 mm
Height 41mm
Input voltage (max.) 264V AC
Length 199mm
Max. output current 14A
Min. input voltage 90V AC
Misc Attribute 1 Synchronised
Misc Attribute 2 HRP-300-24
Misc Attribute 3 closed
No. of inputs 1
No. of outputs 1
Output current (details) 14 A
Output current (max.) - rounded 14A
Output voltage 24 VDC
Output voltage (max.) 24V DC
Power 336W
Weight 953.33g
Width 105mm
