Mean Well HLG-80H-24B LED driver 81.6W 3.4A dimmable surge protection

Mean Well
Order Code:

05-0878

Brand: Mean Well MPN: HLG-80H-24B EAN-13: 4021087009096
Qty Unit Price (Ex VAT)
1+ £38.51
5+ £37.47
10+ £36.54
25+ £36.24
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
17 in stock, despatched in 4 working days

The Mean Well HLG-80H-24B LED driver is a dimmable LED transformer that provides constant voltage and current with a power output of 81.6 W, supporting a current of 3.4 A and a voltage range of 14.4 - 24 V DC. It features surge protection and a PFC circuit, ensuring reliability and efficiency. Typically used for furniture lighting, it is approved for such applications and is equipped with open-end cables for easy installation.
Type LED driver
Connection Open end cable
Dim (L x W x H) 195.6 x 61.5 x 38.8 mm
Height 38.8mm
Input voltage (max.) 277V AC
IP Rating IP67
Length 195.6mm
Max. output current 3.4A
Max. power 81.6W
Min. input voltage 90V AC
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 3.4A
Output voltage (max.) 24V DC
Output voltage (min.) 14.4V DC
Power range 81.6 W (max)
Protection Class I
Width 61.5mm
