Mean Well HLG-40H-24B LED driver 40W 1.67A dimmable IP67 surge protection

Mean Well
Order Code:

05-0851

Brand: Mean Well MPN: HLG-40H-24B EAN-13: 4021087028295
Qty Unit Price (Ex VAT)
1+ £38.66
5+ £36.72
10+ £35.42
25+ £34.42
50+ £32.70
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
9 in stock, despatched in 4 working days

Mean Well's HLG-40H-24B is a versatile LED driver designed for constant voltage and current applications. It features a power rating of 40 W, delivering a current of 1.67 A with a voltage output range of 14.4 - 24 V DC, and includes a dimmable option with PFC circuit and surge protection. This product is ideal for powering LED strips, providing a stable and reliable power supply in various lighting applications.
Type LED driver
Connection Open end cable
Dim (L x W x H) 220 x 100 x 50 mm
Height 50mm
Input voltage (max.) 305V AC
IP Rating IP67
Length 220mm
Max. output current 1.67A
Max. power 40W
Min. input voltage 90V AC
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 1.67A
Output voltage (max.) 24V DC
Output voltage (min.) 14.4V DC
Power range 40 W (max)
Protection Class I
Width 100mm
