Mean Well HLG-40H-12A LED driver 39W 12V IP65 adjustable output PFC

Mean Well
Order Code:

05-0846

Brand: Mean Well MPN: HLG-40H-12A EAN-13: 4021087009584
Qty Unit Price (Ex VAT)
1+ £30.29
5+ £29.50
10+ £28.76
25+ £28.03
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well HLG-40H-12A is a LED driver designed to provide a constant voltage output of 12 V and a constant current of 3.33 A, rated at 39 W. It features a power factor correction (PFC) circuit and surge protection, making it suitable for powering LED strips and other LED applications. This unit can support adjustable operations and is well-suited for various lighting setups requiring open-ended cable connections.
Type LED driver
Connection Open end cable
Dim (L x W x H) 171.00 x 61.50 x 36.80 mm
Height 36.80mm
Input voltage (max.) 305V AC
IP Rating IP65
Length 171.00mm
Max. output current 3.33A
Max. power 39W
Min. input voltage 90V AC
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 3.33A
Output voltage (max.) 12V DC
Power range 39 W (max)
Width 61.50mm
