Mean Well HLG-320H-24AB LED driver 320W dimmable surge protected

Mean Well
Order Code:

05-0829

Brand: Mean Well MPN: HLG-320H-24AB EAN-13: 4021087049467
Qty Unit Price (Ex VAT)
1+ £85.94
5+ £85.29
10+ £84.63
25+ £84.00
50+ £83.36
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well HLG-320H-24AB is a dimmable LED driver with a constant voltage output of 320.16 W, and operates at a current range of 6.67 to 13.34 A with a voltage range of 21 to 26 V DC. It features a 3-in-1 dimmer, adjustable settings, a PFC circuit, and is suitable for outdoor use with surge protection and overvoltage safeguards. Typical applications include powering LED strips
Type LED driver
Connection Open end cable
Dim (L x W x H) 252 x 90 x 43.8 mm
Factory colour Metal
Height 43.8mm
IP Rating IP65
Length 252mm
Max. output current 13.34A
Max. power 320.16W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 13.34A
Output current (min.) 6.67A
Output voltage (max.) 26V DC
Output voltage (min.) 21V DC
Power range 320.16 W (max)
Protection Class I
Test mark MM, SELV, UL, TÜV, CB, CE
Width 90mm
