Mean Well HLG-185H-12AB LED driver 156W dimmable outdoor PFC surge protect

Mean Well
Order Code:

05-0794

Brand: Mean Well MPN: HLG-185H-12AB EAN-13: 4021087049511
Qty Unit Price (Ex VAT)
1+ £58.50
5+ £54.16
10+ £53.54
25+ £52.83
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 29/12/2025

The Mean Well HLG-185H-12AB LED driver is a 156 W constant voltage unit with an adjustable 10.8 - 13.5 V DC output and 6.5 - 13 A current, featuring a 3-in-1 dimmer, PFC circuit, surge protection, and overvoltage capabilities. It is suitable for outdoor use, approved for flammable surfaces and furniture, making it ideal for powering LED strips in a variety of environments.
Type LED driver
Output Voltage 10.8V DC
Max Output Power 156W
Output Current 6.5A
Colour Metal
Connection Open end cable
Dimensions (L x W x H) 228 x 68 x 38.8 mm
Height 38.8mm
IP Rating IP65
Length 228mm
Max. output current 13A
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant voltage
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Protection Class I
Test mark MM, SELV, UL, TÜV, CB, CE
Width 68mm
