Mean Well HBG-200-36 HBG-200 LED driver 198W 36V DC PFC surge protection

Mean Well
Order Code:

05-0732

Brand: Mean Well MPN: HBG-200-36 EAN-13: 4021087049801
Qty Was Unit Price (Ex VAT)
1+ £69.94 £67.77
5+ £64.57 £62.56
10+ £61.34 £59.43
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 14/12/2025

The Mean Well HBG-200-36 is an LED driver that provides constant voltage and constant current of 198 W, 5.5 A, and 36 V DC. It features a PFC circuit, surge protection, and overvoltage protection, making it suitable for outdoor applications. This LED power supply is ideal for powering LED strips and other outdoor LED lighting setups.
Type LED driver
Connection Open end cable
Dim (L x W x H) 132 x 132 x 66.5 mm
Factory colour Black
Height 66.5mm
Inputs 1
IP Rating IP67
Length 132mm
Max. output current 5.5A
Max. power 198W
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 5.5A
Output voltage (max.) 36V DC
Power range 198 W (max)
Protection Class I
Test mark CE, CB, SELV, UL, ENEC
Width 132mm
