Mean Well ELG-75-C1050B-3Y ELG series LED driver 74.55W 1050mA dimmable

Mean Well
Order Code:

05-0513

Brand: Mean Well MPN: ELG-75-C1050B-3Y EAN-13: 4021087037587
Qty Was Unit Price (Ex VAT)
1+ £37.32 £31.34
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well ELG-75-C1050B-3Y is a dimmable LED driver with a constant current of 1050 mA and a power output of 74.55 W. It operates within a voltage range of 35 - 71 V DC and features surge protection and a PFC circuit. This LED driver is suitable for outdoor use, approved for use on furniture, and can be used on flammable surfaces.
Type LED driver
Connection Open end cable
Dim (L x W x H) 180 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
IP Rating IP67
Length 180mm
Max. output current 1050mA
Max. power 74.55W
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 1.05A
Output voltage (max.) 71V DC
Output voltage (min.) 35V DC
Power range 74.55 W (max)
Test mark CE, CB, MM, UL, ENEC
Width 63mm
